LZL VSPC Flooring

* real wood , and waterproof

* Optional underlay for sound insulation

* nature beauty of timber

* Sound Rating: without underlayment: STC 61 & IIC 64

* All kinds of click system suitable

* 5 years commercial use warranty

* 20 years residential use warranty

Inquire Now

Products scenario
Technical parameters

LZL FLOORS
Test Report
						NO: 20220325
生产计划号:		VSPC Sample			生产日期:
Production n° :					Production Date :
面膜型号:					客户型号:
Films model :					Customer's model:
规格:		19001906/1.2mm			检测日期:		20220321
Specification:					Test Date :
No	Test items		Method	Standard			Test results
序号	检测项目		方法	技术指标			检测结果
1	外观 Exterior		Internal	倒角宽度、板面色差、花色、压纹与标准样板一致;油漆要自然，光泽均一，无明显条纹。从600毫米的距离看，表面无划痕、折纹、压痕、鼓包、纸屑、杂物、污斑等。不允许有纸张撕裂、局部缺纸、蚊虫、毛发灰尘、破损、分层等；锁扣易安装，松紧度适宜。Bevel width,color, Sheen,pattern,Texture outlook,Same as the signed master samples.Coating need to looks natural, even,no obvious stripe .From 600 mm distance, the surface without scratches, folds, indentation, bubble, wastepaper, rubbish, dust, Spots, Dirt, etc.Not allowed Paper tear off or missing, mosquito, hair, Damaged,Delamination ,etc.Locking system easy to installed, the lock should be not too tight or loose.Reference number clearly readable, information correct.			Pass
2	尺寸 Dimensions	长 Length	ISO 24337	1900 mm		± 1 mm	1900.06
		宽 Width		190 mm		± 0.15 mm	190.09
3	总厚度Overall thickness		ISO 24337	6.0 mm		± 0.13 mm	6.05
4	边缘直线度 Edge straightness		ISO 24337	≤ 0.5 mm/m			0.2
5	直角度 Squareness		ASTM F2055	qmax≤0.25mm			0.15
6	长度方向翘曲面瓦/背瓦 Peaking/Boming		Internal	Length≥ 800mm :≤6.0 mm；Length＜ 800mm :80% of planks ≤ 0.5% of the length, 20% of planks ≤ 1.0% of the length			0.6
7	宽度方向翘曲面瓦/背瓦 Cupping/Dowing		Internal	For width > 229mm: doming/cupping ≤ 0.2% of the width For width ≤ 229mm: doming/cupping ≤ 0.2 mm			0.03
8	拼装离缝 Installation gap		ISO 24337	锁扣产品Click product:Average ≤ 0.1 mm，Max ≤ 0.20 mm；无锁扣产品Non Click product: ≤ 0.20 mm			0.07
9	拼装高低差 Height difference		ISO 24337	≤ 0.15 mm			0.05
10	气味 smell		Internal	不允许有气味，但是软木和 EVA 会有轻微的气味 No smell allowed ,But the cork and EVA itself can have slight smell			Pass
11	加热翘曲(6h - 60℃) Curl		ISO 23999	≤± 2.0 mm			1.8
12	尺寸稳定性(6h - 60℃) Dimensional stability		ISO 23999	W/ L ≤ 0.2%			0.03
13	脚轮椅 Castor chair		NALFA LF01	在一定转数后(带背垫的产品：1.5万转，不带背垫的产品：2.5万转)，组装状态下评估，没有裂缝，没有分层。 After 15000 rev (product with pre-attached pad) or 25000 rev (product without pad), there's no crack, no delamination			25000r pass
14	锁扣拉力 Click tension force		ISO24334	≥ 125N/152mm			603
15	UV 附着力(百格刀） Coating adhesion		ASTM D3359	≥ 4B			pass
16	厚度吸水膨胀 Thickness swelling		NALFA LF-01 3.2	≤ 2%			0.68
17	微刮擦 Scuff resistance		EN 16094	MSR≥A2，B2			A1，B2
18	耐磨 Abrasion		ANSI/HPVA EF 2002 ASTM D4060	Handscraped ≥ 200 rev, Brushed ≥ 300 rev, Flat ≥ 500 rev			500 r
结论			■合格 - Qualified			□不合格Unqualified
Conclusion			处理结果Handle:
